Startech 4 Port RS232 PCI Express Serial Card w/ Breakout Cable

  • Lagerstatus: Sendes innen 48 timer
  • Frakt fra: 99 kr
  • Artikkelnr.
  • 5010945578
  • Prod. art. nr.
  • PEX4S553B

Produktinformasjon

The PEX4S553B 4-Port PCI Express Serial Card (with breakout cable) lets you add 4 RS232 serial ports using a single PCIe expansion slot. The PCIe Serial Card includes a 1-to-4 break out cable, which enables you to add 4 serial ports to a single low profile slot.The serial adapter card features a native single-chip design that provides optimum reliability and speed, reducing the CPU load by up to 48% over conventional bridge-chip serial cards - a cost-effective solution for connecting legacy serial devices to PCIe-enabled computers.The multi-port serial adapter includes both full profile/height and low profile/half-height brackets for compatibility with standard and small form factor computers, and is compatible with a broad range of operating systems, including Windows 7/Server 2008 R2, 2003/Vista/XP (32 and 64 bit), Linux Kernel 2.6.11 and up, as well as MAC OS 10.5 and above.This product is a replacement for the PEX4S552B card.

Spesifikasjoner

Topptekst
Produsent StarTech.com
Antall pakker 1
Modell 4 Port RS232 PCI Express Serial Card w/ Breakout Cable
Produktserie StarTech.com
Nettverk og kommunikasjon
Tilkoblingsteknologi Kablet
Dataforbindelseprotokoll RS-232
Datakjedeprotokoll RS-232
Dataoverføringshastighet 0.25 Mbps
Systemkrav
Støtte for operativsystem Microsoft DOS, Linux, Microsoft Windows 2000, Microsoft Windows CE 5.0, Microsoft Windows Embedded POSReady 2009, Microsoft Windows Server 2008 R2, Microsoft Windows 95/98 Second Edition, Microsoft Windows Vista (32/64 bits), Microsoft Windows CE 6.0, Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits), Apple MacOS X 10.x, Microsoft Windows XP Embedded
Tilpassede standarder
Kompatible standarder RoHS
Miljøparametre
Min. driftstemperatur 0 °C
Maks. driftstemperatur 70 °C
Luftfuktighet ved drift 5 - 85%
Ekspansjon / Tilkoplinger
Tilkoblinger 4 x RS-232 - 9 pin D-Sub (DB-9)
Størrelser og vekt
Yttermål Bredde 2 cm
Yttermål dybde 7 cm
Yttermål Høyde 6.2 cm
Vekt 0.226 kg
Service og støtte
Service & support Begrenset livstidsgaranti, Livstidsgaranti
Service & Support
Service & Support Details Limited warranty - lifetime
Generelt
Nettverkstilknytning / Grensesnitts(databuss)-type PCI Express
Nettverkstype Seriell adapter
Enhetstype Serial adapter
Formfaktor Internal
