Nettverksbygging
Nettverksstandard
IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af/at, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet-kobberkabelteknologi
1000BASE-T, 1000BASE-X, 100BASE-T, 10BASE-T
Address Resolution Protocol (ARP)-oppføringer (maks.)
4096
MAC-adresse automatisk læring støttes
Ja
Strømningskontroll støtte
Ja
Ethernet Ring Protection Switching (ERPS)
Ja
Linkaggregasjon/Linksamling
Ja
Neighbor Discovery Protocol (ND)-oppføringer
3000
Ethernet LAN dataoverføringshastigheter
10, 100, 1000 Mbit/s
Virtuelle LAN-funksjoner
MVRP, Port-based VLAN, Private VLAN, Tagged VLAN, Voice VLAN
Tekniske detaljer
Samsvarssertifikat
BSMI, Elektromagnetisk kompatibilitet (EMC), Federal Communications Commission (FCC), RoHS, REACH, UL, FCC, BSMI, KC, VCCI, UKCA, CE, CB, RCM, Ukraina DOC, Marokko DOC, VCCI
Sikkerhet
DHCP-funksjoner
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping
Access Control List (ACL)/tilgangskontrolliste
Ja
Sikkerhetsalgoritmer
802.1x RADIUS, EAP, HTTPS, MD5, PEAP, SNMP, SNMPv2, SNMPv3, SSH-2, TLS, TTLS
Køplanleggingsalgoritmer
SP (programvare), Weighted random early detection (WRED)
Persistent MAC Learning (Sticky MAC)
Ja
Autentisering
MAC-basert autentisering
Autentiseringstype
AAA, IEEE 802.1x, RADIUS, TACACS+
Styringsfunksjoner
Quality of Service (QoS) støtte
Ja
Configuring Location Settings (CLI)
Ja
MIB-støtte
RFC 1155 SMI RFC 1157 SNMPv1 RFC 1212, RFC 1213, RFC 1215 MIB-II, Ethernet-Like MIB and TRAPs RFC 1493 Bridge MIB RFC 1643 Ethernet MIB RFC 1657 BGP-4 MIB RFC 1724 RIPv2 MIB RFC 1850 OSPFv2 MIB RFC 1905 RFC 1907 SNMP v2c, SMIv2 and Revised MIB-II RFC 2011 SNMPv2 for Internet Protocol using SMIv2 RFC 2012 SNMPv2 for transmission control protocol using SMIv2 RFC 2013 SNMPv2 for user datagram protocol suing SMIv2 RFC 2096 IPv4 Forwarding Table MIB RFC 2287 System Application Packages MIB RFC 2570–2575 SNMPv3, user based security, encryption, and authentication RFC 2576 Coexistence between SNMP Version 1, Version 2 and Version 3 RFC 2578 SNMP Structure of Management Information MIB RFC 2579 SNMP Textual Conventions for SMIv2 RFC 2665 Ethernet-like interface MIB RFC 2787 VRRP MIB RFC 2819 RMON MIB RFC 2863 Interface Group MIB RFC 2863 Interface MIB RFC 2922 LLDP MIB RFC 2925 Ping/Traceroute MIB RFC 2932 IPv4 Multicast MIB RFC 3413 SNMP Application MIB RFC 3414 User-based Security model for SNMPv3 RFC 3415 View-based Access Control Model for SNMP RFC 3621 PoE-MIB (PoE switches only) RFC 4188 STP and Extensions MIB RFC 4363 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and VLAN extensions RFC 5643 OSPF v3 MIB support Draft – blumenthal – aes – usm - 08 Draft – reeder - snmpv3 – usm - 3desede -00 Draft-ietf-bfd-mib-02.txt Draft-ietf-idmr-igmp-mib-13 Draft-ietf-idmr-pim-mib-09 Draft-ietf-idr-bgp4-mibv2-02.txt – Enhanced BGP-4 MIB Draft-ietf-isis-wg-mib-07
Protokoller
Virtual Router Redundancy Protocol (VRRP)
Ja
Routerprotokoll
BGP, IS-IS, OSPF, OSPFv3, RIP-1, RIP-2, RIPng
Power over Ethernet (PoE)
Strøm over Ethernet (PoE)
Ja
Antall Power over Ethernet plus (PoE+)-ports
8
Power over Ethernet (PoE) støttes
PoE+
Power over Ethernet (PoE) effekt per port
30 W
Total Power over Ethernet (PoE)-budsjett
120 W
